HS-6103F SINGLE PHASE ENERGY METER TEST BENCH

with 40 positions for electronic kWh meter, fission type by two fixing racks, automatic change to calibrate/test line and neutral

This specification for single phase dual loop energy meter test bench.

Voltage Source:

1. Output Voltage Range: 0- 275/300V

2. Output Max Power: 800VA

3. Resolution: 0.01%

4. Stability: Better than 0.05% / 3 Min(Time base 5S)

5. Distortion factor: < 0.5% at linear load;

6. Frequency range: 45Hz~65Hz;

7. Power efficiency: more than 85%;

8. Ambient temperature:10℃~50℃

9. Electronic overload and short-circuit protection.

Current Source:

1. Output current: range: 1mA~100A+/-20%;

2. Output maximum power: 2000VA

3. Resolution: 0.01%;

4. Stability: better than 0.05%/3 min(time base 5S);

5. Distortion factor: < 0.5% at linear load;

6. Frequency range: 45Hz~65Hz;

7. Power efficiency: greater than 85%;

8. Ambient temperature:10℃~50℃

9. Electronic overload protection and security for open current circuit.

Reference Meter:

HS-5100 Single Phase Reference Meter Accuracy class: 0.05%

Accessories:

1. Phase Angle: 0°~360°, resolution of phase angle setting: 0.1°;

2. Output frequency range: 45Hz~65Hz; resolution: 0.01Hz

3. Output stability of power: <0.05% (180S)

4. Input power: 230~240V±10%, 50/60Hz;

5. RS232 connectors for each position to be connected to Serial Ports Server,(for meter calibration & programming)

6. Current Connection Type: LNNL (1-4, 3-2) (Dual Loop)

Main Information:

Dimensitions:

DELIVERY

We are the manufacturer of HS Series Single & Three-Phase Energy meter Test Bench.
